| 品牌：SMAC | 型号：VLC-M1 | 用途：提供动力 |
| 是否支持加工定制：否 | 是否进口：否 | 产品名称：VLC-M1 |
| 产品认证：CE | 供电方式：48V | 适用范围：CE |
| 产品特性：运动控制器 | 产地：美国 | 加工定制：否 |
The VLC-M1is a single axis DC brushed/brushless motor controller/driver, designed and manufacturedby SMAC in the United States. With a US list price of $300.
Customizations of the VLC to specific design and market/customer needs are possible.These efficiencies result in a considerable cost-savings to the end customer.
特点
Competitive pricing.
Stand-alone or built-in type available.
With a built-in type, physical shape can be adjusted to fit specific space requirements.
Very compact with 3.5 amp continuous and 6.5 amp peak driver.
Same programming language as LAC-1,standard serial terminalFREE software.
Same programming language as LAC-1,standard serial terminalFREE software.
技术规范
| Operating Mode | Position, Velocity, Torque |
| Filter Algorithm | PID |
| Max. servo Loop Rate | 100S |
| Trajectory Generator | Trapezoidal |
| Servo Position Feedback | Incremental Encoder with Index |
| Output (Standard) | PWM (space-vector-modulated), 3.***mps Cont. and 6.5 Amp Peak at 50 VDC Max. |
| Motor Type | 3-Phase Brushless, DC Brushed, DC linear Actuator |
| PQM Frequency | 20.0KHz |
| Current Resolution | 5.66mA |
| Encoder and Index Input | Differential |
| Encoder Supply Voltage | 5VDC |
| Encoder Input Voltage | 5.5VDC Max., -0.1VDC Min. |
| Encoder Count Rate | >2 Million Quadrature Counts per Second |
| Position Range | 31 Bits |
| Velocity Range | 31 Bits |
| Acceleration Range | 31 Bits |
| General Purpose Digital I/O | 2x PLC level lated digital inputs |
| User Analog Input | 1x 0-10V with 12-Bit Resolution |
| LEDs | 2 LEDs:
|
| Serial Interface | RS-232 non-lated, 9600 baud default, selectable between 2400 - 460800 |
| Supply Voltage | +8 To +50VDC |
| Protections |
|
| Program Space |
|
